3D Printing Medicines (Review articles)

We have recently published three interesting reviews in collaboration with University college London (UCL) about different aspects of the applications and challenges of 3D printing in the pharmaceutical sector.

You can find the articles following the links below. Contact us for reprints or to talk about new applications.

Pharmaceutical researchers are becoming more interested in the use of three-dimensional printing (3DP) to manufacture medicines. Since 3DP is a highly flexible technique to manufacture personalised objects, 3DP can potentially become a new method to fabricate patient-tailored printlets (3D printed tablets).

Different 3DP systems have been explored for their use in Pharmaceutics, including fused deposition modelling (FDM), selective laser sintering (SLS), powder liquid and recently stereolithography (SLA). SLA has some advantages over other types of 3DP, mainly its remarkable resolution and the avoidance of thermal processes which can be detrimental for certain drug molecules.

What is stereolithography?

Stereolithography (SLA) 3D printing is an additive manufacturing process where a photocurable liquid resin is solidified in a highly accurate, controlled and rapid way.

Schematic representation of an SLA 3D printer

In SLA 3D printing the solidification of the building material occurs in a layer by layer manner by means of a photopolymerisation process. During photopolymerisation, 3-dimensional crosslinked networks are formed upon exposure to an appropriate source of light which allows the possibility of fabricating hydrogels.

mage of a Form 1+ SLA 3D printer (Formlabs Inc.)

Why hydrogels are important

Hydrogels are three-dimensional hydrophilic polymeric networks, which are able to absorb large amounts of water or other liquid agents hence having gel behaviour. This property makes hydrogels great candidates for their use for biomedical purposes, for instance in tissue engineering and in drug delivery systems. The use of hydrogels as medicines allows the possibility of having a controlled release of drugs over time from these polymeric matrices which is desirable to enhance efficacy and safety.

SLA 3D printed hydrogels

Researchers at the UCL School of Pharmacy fabricated for the first time ibuprofen-containing hydrogel printlets using a highly biocompatible photoinitiator (which is a molecule capable of initiating a light-triggered polymerisation process) and a commercial desktop SLA 3D printer. The hydrogels had different contents of initial water in the liquid formulation to modify the speed at which the drug is released from the printlets which can be useful to tailor drug release profiles to the individual needs of patients.

Images of hydrogels printlets containing ibuprofen fabricated using SLA printing

How is the drug contained in the printlets and how is it released?

During 3D printing the drug becomes entrapped in between the polymer crosslinked network. When the printlets are placed in water, they swell as the network loosens. When this happens, the drug molecules are released in a controlled manner. Depending on multiple factors including how tight the polymer networks are, the drug release can be modified, in this research since the hydrogels retain the water added prior to printing, this acts as a pre-swelling agent that increases the drug release rate.

Drug dissolution profiles from the hydrogel printlets. The drug released was determined in a dynamic dissolution system to mimic the conditions in the gastrointestinal tract; the red line shows the pH values of the media.

The Potential of SLA 3DP in the Pharmaceutical area

SLA can become a new method for fabricating drug-loaded hydrogels with tunable mechanical and physical properties and drug release profiles. SLA avoids the risk of thermal degradation and additionally offers a way to fabricate highly complex structures with a great resolution, which can be useful to modify the way in which the drug is released.

The use of 3-dimensional printing (3DP) in the healthcare industry is becoming an increasingly popular trend. 3DP allows the manufacturing of personalized-dose medicines to be tailored to the individual combining different drugs. The replacement of conventional drug manufacture and distribution could provide patients with personalized polypills fabricated at the point of care, thus reducing cost and enhancing therapy adherence. The FDA approval, in August 2015, of the first 3D printed medicine (Spritam®) proved that 3DP technology works and the race is now on to push forward its development in the pharmaceutical field.

3D printing technologies

In recent years different 3DP technologies have been used to produce these new medicines e.g. stereolithography (SLA) or fused deposition modeling (FDM), which has been the most employed 3DP technology to date, due to it being inexpensive and easy to use.

Printlets, 3D printed tablets

Researchers from FabRx Ltd. and UCL – School of Pharmacy have recently reported in the International Journal of Pharmaceutics the use, for the first time, of selective laser sintering (SLS) to produce personalised 3D printed tablets (Printlets™).

What about selective laser sintering (SLS)?

Selective laser sintering is currently used for industrial manufacturing of plastic, metallic and ceramic objects but, to date, there have been no reports on the use of SLS to fabricate oral drug loaded products.

Schematic representation of the SLS printer (Fabrizio Fina)

SLS uses a laser to bind together the powder particles from a powder bed. During the printing process, the laser is directed to draw a specific pattern onto the surface of the powder bed. Once the first layer is completed, a roller distributes a new layer of powder on top of the previous one. The object is built layer-by-layer, which is then recovered from underneath the powder bed. Advantages of SLS technology include the fact that it is a solvent-free process and offers faster production and resolution compared to other methods.

Is it an industrial process?

In this first study paracetamol (acetaminophen) was selected as a model drug, mixed with pharmaceutical excipients and incorporated in the powder bed of a commercial desktop SLS 3D printer, Sintratec kit. Sintratec printer is the first desktop printer in the market which makes SLS accessible to consumer customers.

Image of a Sintratec kit desktop SLS 3Dprinter

Sintratec SLS technology has enabled printing of personalized-dose printlets of different shapes, with high resolution and no drug degradation. The SLS technology offers a platform technology to formulate and manufacture 3D printed medicines with almost any drug compound in a range of shapes, sizes, colours, textures and flavours to make them more attractive to various patient groups, particularly the young or the elderly, facilitating compliance of the treatment. The manufacturing process allows precision of dose strength and is suitable for both low and high drug concentrations.

Images of printlets containing paracetamol (acetaminophen) prepared by SLS printing

How is the drug release?

Drug release tests from the printlets were performed in a Dynamic Dissolution Model that modulates pH over time, precisely simulating gastro intestinal conditions during transit of the medicines. Proper selection of excipients allows FabRx to design printlets possessing any desired drug release profile, ranging from immediate release to sustained and delayed release.

Drug dissolution profiles from printlets. Red line shows the pH values of the media

The Potential of SLS printing in Pharmacy

The new technology provides the means for producing personalized medicines that can be adapted to individual patients’ requirements. The technology offers a simple, fast method to fabricate personalized drug-loaded, high resolution printlets with any drug compound. SLS appears to be a versatile and practical 3D printing technology which can be applied to the pharmaceutical field, thus widening the armamentarium of 3D printing technologies available for the manufacture of modern medicines.
